Philippine NPC Electric Steel Tubular Floodlight Pole With Hot Dip Galvanization

Brand Name : MilkyWay

Model Number : Steel Tubular Pole

Certification : ISO9001 / BV /

Place of Origin : China

MOQ : 1 pcs

Price : Negotiation

Payment Terms : T/T, L/C at sight

Supply Ability : 300pcs per day

Delivery Time : 20 working days after received your payment

Packaging Details : As customer request

Product Name : Floodlight Pole

Power : 10 KV ~550 KV

Torlance of the dimenstion : +- 2%

Flange size : 450mm

Wall thickness : 3mm

Contact Now

Philippine NPC Electric Steel Tubular Pole with Hot Dip Galvanization

Steel
The material is in accordance with NF EN 10025
Standard and NF EN 10149 Standard,it has the following property.
-Yield Strength=355N/mm2
-Toughness remains the same under 20 degrees below zero.
-Galvanization is in accordance with NFA35503 Standard Class 1.

Steel Material Grade
China GB America ASTM ASME Japan JIS Europen
EN		 Gemany
DIN		 England
BS		 International
ISO
16Mn
14MnNd
Q345(A.B.C.D.E)		 A572MGr.50
A633MGr.C
A633MGr.D		 SM490A
SM490B
SM490C		 S355JR
S355JOS
355J2G3
S355J2G
4S355K2
G3
S355K2G
4S355N
S355NL		 St52-3 50A
50B
50C
50D
50DD		 E355DD
E355E
Fe510B
Fe510D
WH60/Q460
( C.D.E)		 A572MGr.65 SM570 S460N
S460NL		 StE460 55C
55E		 E460C
E460D
Q235
( A.B.C.D)
Q275
20
25
30
35
40
45
50
55
50Mn		 A283MGr.C
A283MGr.D
1020
1025
1030
1035
1040
1045
1050
1055
1053		 SS400
SM400( A B)
SS490
S20CS22C
S25C S28C
S30C S33C
S35C S38C
S40C S43C
S45C S48C
S50C S53C
S55C S58C
SWRH52B		 S235JR
S235JO
S235J2G
3
1C22
1C25
1C30
1C35
1C40
1C45
1C50
1C55
2C50		 St37-2
St37-3
1C22
1C25
1C30
1C35
1C40
1C45
1C50
1C55
2C50		 40A
40B
40C
40D
1C22
1C25
1C30
1C35
1C40
1C45
1C50
1C55
2C50		 Fe360
( A.B.C.D)
Fe430A
C25E4
C30E4
C35E4
C40E4
C45E4
C50E4
C55E4
SL, SM

Philippine NPC Electric Steel Tubular Floodlight Pole With Hot Dip Galvanization

Welding
We have past flaw testing. Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1

Philippine NPC Electric Steel Tubular Floodlight Pole With Hot Dip Galvanization

Galvanization
Standard:NFA91121
Average thickness of the galvanization:Not less than 86μm.

Philippine NPC Electric Steel Tubular Floodlight Pole With Hot Dip Galvanization

Specification:

Philippines NPC Specification
ITEM STEEL POLE
TYPE LENGTH TIP DIAMETER BUTT DIAMETER THICKNESS
(FT) (MM) (MM) (MM)
1 B 50 200 370 6
2 E 50 200 585 6
3 HT 50 200 520 6
4 B 55 200 395 6
5 E 55 200 625 6
6 HT 55 200 550 6
7 B 60 200 415 6
8 C 60 250 730 6
9 D 60 300 765 7
10 E 60 200 660 6
11 HS 60 200 400 6
12 HT 60 200 580 6
13 B 65 200 435 6
14 C 65 250 770 6
15 D 65 300 755 8
16 E 65 200 700 6
17 HT 65 200 615 6
18 B 70 200 455 6
19 C 70 250 805 6
20 D 70 300 790 8
21 E 70 200 740 6
22 HT 70 200 645 6
23 3T 70 250 640 6
24 3D 70 300 765 6
25 spare type D 70 300 790 8

Quality Control

We strictly follow the standard of ISO9001-2008. Quality is in the first place at every stage of production to ensure the product compliance to the specification/standards. Careful inspections are carried out by highly trained inspection engineers during every procedure from raw material stage to finished product and delivery.
