16m transmission line steel pole tower & Power Transmission Poles

Brand Name : Milky Way

Model Number : 16m

Certification : ISO//BV

Place of Origin : China

MOQ : one 40HQ

Price : negotiation

Payment Terms : T/T

Supply Ability : 300 pieces pole per day

Delivery Time : usually 2 weeks after confirming

Packaging Details : as per customer request

Tolerance Of Dimension : +- 2%

Wind Resistance : 3-500km/h

Material : GR50 GR65 S500 S355

Height : 16m

Welding : Welding confirms with international welding standard of CWB

Powder coating : Pure polyester powder painting, color is optional

Design : Against 8 Grade Of Earthquake

Product Name : 16m transmission line steel pole tower & Power Transmission Poles

Contact Now


Specification

Item TIP DIAMETER BUTT DIAMETER THICKNESS Pole Shape
(m) (MM) (MM) (MM) 8 sides
11.8m/5KN 150 355 3
11.8m/6.5KN 180 400 3
11.8m/8KN 190 440 3
11.8m/10KN 190 450 3.5
11.8m/12.5KN 220 500 3.5
11.8m/16KN 230 560 3.5
11.8m/20KN 240 585 4
11.8m/25KN 260 655 4
11.8m/32KN 260 660 5
11.8m/40KN 260 670 6
16m/5KN 150 375 4
16m/6.5KN 180 420 4
16m/8KN 190 460 4
16m/10KN 190 510 4
16m/12.5KN 220 525 4 12 sides
16m/16KN 230 585 4
16m20KN 240 585 5
16m/25KN 260 655 5
16m/32KN 260 670 6


To assure our products qualified ,we take steps as follows :

1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management .
2. Introducing ISO management ,We are awared ISO 9001:2008 certificate.
3. QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment.

Material High-quality steel Q235/SS400 from BAOSTEEL Group
Welding Technique Automatic submerged arc welding
Surface Treatment Hot dip galvanizing and powder painting
Welding Standard GB11345 Grade Ⅱ
Thickness of Zinc Coating ≥ 86um
Adhesive Force of Zinc Coating GB2694-88
Anti-wind Capacity 36.9m/s
Anti-corrosion Lifetime ≥20 years
Coating Layer Thickness ≥100um
Adhesive force GB9286-880
Hardness ≥2H
Steel Pole Height Options 3.5m~15m
Street Lighting Poles Type Options

Conical, polygonal



Company Introduction:

Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Company has 24 years experience on producing the steel poles including the transmission power pole,street light pole,high mast pole and so on.
We exported to oversea countries since 1991 and our products have been delivered to more than 70 countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa and so on.
We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the high mast pole for Sochi Winter Olympic Game and so on.

Competitive Advantage:

1. Easy work: more than 23 years pole field. quickly understand your meaning and let you get your result.
2. Lowest MOQ: lowest quantity from 1Ton depends on different style .
3. OEM Accepted: We can produce any pole of your design.
4. Good Service: We treat clients as friends.
5. Good Quality: We have very strict quality control system .Good reputation in the market.
6. Fast & Cheap Express service: We have big discount from forwarder (Long-term Contract with TNT,DHL,UPS,FEDEX,EMS ).
7. Manufacturer Capacity : 300 pieces/day.


16m transmission line steel pole tower & Power Transmission Poles

Best Service: --At Jiangsu Milky Way Steel Poles Co.,Ltd, our #1 priority has always been providing our clients with great quality products and superior Customer service.
Quick Lead Time.--We're dedicated to providing the quickest turnaround times and work Hard to
ensure that all of your deadlines are meet.
Unbeatable Prices-- We continuously strive to find ways of reducing our production costs, and passing the
savings Over to you!
Unbeatable Quality --we always supply good quality also leading products to our VIP customers.
Brand Awareness -- The goal of any strong brand is achieve a level of awareness that instills the
idea of quality and value into all of your customers.
Special Offers. -- In order to maintain our competitive edge, we are constantly running special offers on
our products, consumer goods, and design services. Contact our sales team to see how we can
help you save a lot of money.
Special support.-- we have a policy term to support our VIP customers for products also payment.
